Table:
D200Z
복잡한 3차원 형상의 워크를 우수한 정도와 면품질로 가공할 수 있는, 응답성 높은 회전축을 탑재한 5축 가공기입니다.
Table:
Φ 300 mm
X:
350 mm
Y:
300 mm
Z:
250 mm
Rapid Traverse:
60 m / min
Table:
Φ 300 mm
X:
300 mm
Y:
500 mm
Z:
350 mm
Rapid Traverse:
60,000 mm/min
Maximum Workpiece:
Φ 450 x 240 mm (조건부)
Pallet:
400 x 400 mm
Table:
Φ 500 mm
X:
550 mm
Y:
1,000 mm
Z:
500 mm
Rapid Traverse:
X : 48,000 mm/min
Y/Z : 50,000 m/min
Maximum Workpiece:
650 mm x 500 mm(H) (조건부)
Table:
ø 800 mm
X:
1,200 mm
Y:
1,100 mm
Z:
650 mm
Rapid Traverse:
36,000 mm/min
Maximum Workpiece:
ø 1,000 mm x 500 mm (제한)
Spindle Taper:
BT40 (Opt. HSK-A63)
Table:
1600 mm x 1200 mm
X:
2200 mm
Y:
2300 mm
Z:
1100 mm
Rapid Traverse:
35000mm/min(X/Y 축), 45000mm/min(Z축), 10000mm/min(W 축), 7200/10800/3600°/min(A/B/C 축)
Maximum Workpiece:
ø2100 mm x 1700 mm
Table:
300 mm x 340 mm
X:
450 mm
Y:
620 mm
Z:
500 mm
Rapid Traverse:
60,000 mm/min
Maximum Workpiece:
ø450 mm x 400 mm (조건부)
Table:
1,300 mm x 1,000 mm
X:
1,300 mm
Y:
1,000 mm
Z:
600 mm
Rapid Traverse:
58,000 mm/min
Maximum Workpiece:
1,500 mm x 1,200 mm x 550 mm
Table:
2,000 mm x 1,300 mm
X:
2,000 mm
Y:
1,300 mm
Z:
800 mm
Rapid Traverse:
58,000 mm/min
Maximum Workpiece:
2,200 mm x 1,500 mm x 700 mm
Table:
2000 × 2500 mm
X:
2,000 mm
Y:
2,500 mm
Z:
800 mm
Rapid Traverse:
58000mm/분(X/Z축), 25000mm/분(Y축), 12600/21600°/분(A/C 축)
Maximum Workpiece:
2,000 mm x 2,500 mm x 1,050 mm
